The hydraulic breakers are designed with INTACA patents. No matter what is the bad situation in the wilds or in the cities where are strictly noise level control, the breaking tasks such as concrete, reinforced concrete, asphalt and rock can be performed effectively and safely.
◎Features
◆ Small size and light weight
◆Powerful impacting energy and low reverse impacting
◆Low noise, high reliability, and durable working
◆Breaking bits for different demands
Specifications
|
Type |
BK18 |
BK18S |
BK20 |
BK20S |
BK28 |
BK28S |
|
Weight(kg) |
18 |
19 |
20 |
21 |
28 |
29 |
|
Output flow(lpm) |
15-24 |
15-24 |
26-34 |
26-34 |
26-34 |
26-34 |
|
Operating pressure(bar) |
90-140 |
90-140 |
105-140 |
105-140 |
105-140 |
105-140 |
|
Impact frequency(bpm) |
1800-2400 |
1800-2400 |
1800-2400 |
1800-2400 |
1800-2400 |
1800-2400 |
|
Bits size(in. Hex) |
1x4-1/4 |
1x4-1/4 |
1x4-1/4 |
1x4-1/4 |
1-1/4x6 |
1-1/4x6 |
|
Model of handle |
T-handle |
Anti-vibration handle |
T-handle |
Anti-vibration handle |
T-handle |
Anti-vibration handle | |
